SoftmaxFlashV3

def softmax_flash_3(src, height, width, loopCnt, alpha, baseK, inmax=None, insum=None, inmean=None, update=False):
    scalar = alapha / (1 - alapha)
    #(m,n)->(m,64)
    tmpbuffer0 = BlockReduceSum(repeatSize, repeatSize, elementNumPerBlk)
    remain = int(width / repeatSize - BlkcntPerRepeat)
    tmpbuffer0 = Add(tmpbuffer0, src, remain, repeatSize * elementNumPerBlk, width)
    #(m,64)->(m,8)
    tmpbuffer0 = BlockReduceSum(1, relementNumPerBlk, elementNumPerBlk)
    #width = baseK * splitMeanCnt
    rowMeanLocal = tmpbuffer0 / baseK
    rowMeanGlobal = np.mean(src, axis=(-1), keepdims=True)
    rowMeanGlobalTmp = (rowMeanGlobal - rowMeanLocal) * scalar
    src = src - rowMeanGlobalTmp

    if update == False:
        x_mean = rowMeanGlobal
        maxTmp = np.max(src, axis=-1, keepdims=True)
        shiftCurr = (rowMeanGlobal - x_mean) * scalar
        x_max = shiftCurr + maxTmp
        maxTmp = x_max - shiftCurr
        x_sub = src - maxTmp
        dst = np.exp(x_sub)
        x_sum = np.sum(dst, axis=-1, keepdims=True)
        exp_max = None
        return dst, x_max, x_sum, x_mean, exp_max
    else:
        x_mean = (rowMeanGlobal + inmean * (loopCnt - 1)) / loopCnt
        maxTmp = np.max(src, axis=-1, keepdims=True)
        shiftCurr = (rowMeanGlobal - x_mean) * scalar
        shiftPrev = (inmean - x_mean) * scalar
	x_max = shiftCurr + maxTmp
        maxTmp = shiftPrev + inmax
        x_max = np.max(np.concatenate((x_max, maxTmp), axis=(-1)), axis=(-1), keepdims=True)
        maxTmp = x_max - shiftCurr
        x_sub = src - maxTmp
        dst = np.exp(x_sub)
        exp_max = np.exp(inmax - x_max + shiftPrev)
        x_sum = np.sum(x_exp, axis=-1, keepdims=True)
        x_sum = exp_max * insum +  x_sum
        return x_exp, x_max, x_sum, x_mean, exp_max

#include "kernel_operator.h"

template <typename T, typename U>
class KernelSoftmaxFlashV3 {
public:
    __aicore__ inline KernelSoftmaxFlashV3() {}
    __aicore__ inline void Init(__gm__ uint8_t *srcGm, __gm__ uint8_t *inMaxGm, __gm__ uint8_t *inSumGm,
       __gm__ uint8_t *inMeanGm, __gm__ uint8_t *dstGm, const SoftMaxTiling &tilingData)
    {
        srcGlobal.SetGlobalBuffer((__gm__ T *)srcGm);
        dstGlobal.SetGlobalBuffer((__gm__ T *)dstGm);
        maxGlobal.SetGlobalBuffer((__gm__ U *)inMaxGm);
        sumGlobal.SetGlobalBuffer((__gm__ U *)inSumGm);
        meanGlobal.SetGlobalBuffer((__gm__ U *)inMeanGm);
        pipe.InitBuffer(inQueueSrc, 1, height * width * sizeof(T));
        elementNumPerBlk1 = 32 / sizeof(U);
        pipe.InitBuffer(maxQueue, 1, height * elementNumPerBlk1 * sizeof(U));
        pipe.InitBuffer(sumQueue, 1, height * elementNumPerBlk1 * sizeof(U));
        pipe.InitBuffer(meanQueue, 1, height * elementNumPerBlk1 * sizeof(U));
        elementNumPerBlk2 = 32 / sizeof(T);
        pipe.InitBuffer(expMaxQueue, 1, height * elementNumPerBlk2 * sizeof(T));
        pipe.InitBuffer(outQueueDst, 1, height * width * sizeof(T));
        tiling = tilingData;
    }
    __aicore__ inline void Process()
    {
        CopyIn();
        Compute();
        CopyOut();
    }

private:
    __aicore__ inline void CopyIn()
    {
        AscendC::LocalTensor<T> srcLocal = inQueueSrc.AllocTensor<T>();
        AscendC::LocalTensor<U> insumLocal = sumQueue.AllocTensor<U>();
        AscendC::LocalTensor<U> inmaxLocal = maxQueue.AllocTensor<U>();
        AscendC::LocalTensor<U> inmeanLocal = meanQueue.AllocTensor<U>();
        AscendC::DataCopy(srcLocal, srcGlobal, height * width);
        AscendC::DataCopy(insumLocal, sumGlobal, height * elementNumPerBlk1);
        AscendC::DataCopy(inmaxLocal, maxGlobal, height * elementNumPerBlk1);
        AscendC::DataCopy(inmeanLocal, meanGlobal, height * elementNumPerBlk1);
        inQueueSrc.EnQue(srcLocal);
        sumQueue.EnQue(insumLocal);
        maxQueue.EnQue(inmaxLocal);
        meanQueue.EnQue(inmeanLocal);
    }
    __aicore__ inline void Compute()
    {
        AscendC::LocalTensor<T> srcLocal = inQueueSrc.DeQue<T>();
        AscendC::LocalTensor<U> insumLocal = sumQueue.DeQue<U>();
        AscendC::LocalTensor<U> inmaxLocal = maxQueue.DeQue<U>();
        AscendC::LocalTensor<U> inmeanLocal = meanQueue.DeQue<U>();
        AscendC::LocalTensor<T> expMaxTensor = expMaxQueue.AllocTensor<T>();
        AscendC::LocalTensor<T> dstLocal = outQueueDst.AllocTensor<T>();
        AscendC::SoftMaxParams params = {height, width, height, width, loopCnt, splitMeanCnt, alpha};
        AscendC::SoftmaxFlashV3<T, U, true>(dstLocal, inmeanLocal, insumLocal, inmaxLocal, srcLocal, expMaxTensor, inmeanLocal, insumLocal, inmaxLocal, tiling, params);

        outQueueDst.EnQue<T>(dstLocal);
        maxQueue.FreeTensor(inmaxLocal);
        sumQueue.FreeTensor(insumLocal);
        meanQueue.FreeTensor(inmeanLocal);
        inQueueSrc.FreeTensor(srcLocal);
    }
    __aicore__ inline void CopyOut()
    {
        AscendC::LocalTensor<T> dstLocal = outQueueDst.DeQue<T>();
        AscendC::DataCopy(dstGlobal, dstLocal, height * width);
        outQueueDst.FreeTensor(dstLocal);
    }

private:
    AscendC::TPipe pipe;
    AscendC::TQue<AscendC::TPosition::VECIN, 1> inQueueSrc;
    AscendC::TQue<AscendC::TPosition::VECIN, 1> meanQueue;
    AscendC::TQue<AscendC::TPosition::VECIN, 1> maxQueue;
    AscendC::TQue<AscendC::TPosition::VECIN, 1> sumQueue;
    AscendC::TQue<AscendC::TPosition::VECIN, 1> expMaxQueue;
    AscendC::TQue<AscendC::TPosition::VECOUT, 1> outQueueDst;
    AscendC::GlobalTensor<T> srcGlobal, dstGlobal;
    AscendC::GlobalTensor<U> meanGlobal, maxGlobal, sumGlobal;
    uint32_t elementNumPerBlk1 = 0;
    uint32_t elementNumPerBlk2 = 0;
    uint32_t width = 1024;
    uint32_t height = 8;
    uint32_t loopCnt = 2;
    uint32_t splitMeanCnt = 8;
    float alpha = 0.9375;
    SoftMaxTiling tiling;
};

extern "C" __global__ __aicore__ void softmax_flashv3_kernel(__gm__ uint8_t *srcGm,
    __gm__ uint8_t *inMaxGm, __gm__ uint8_t *inSumGm, __gm__ uint8_t *inMeanGm, __gm__ uint8_t *dstGm, __gm__ uint8_t *tiling)
{
    GET_TILING_DATA(tilingData, tiling);
    KernelSoftmaxFlashV3<half, float> op;
    op.Init(srcGm, inMaxGm, inSumGm, inMeanGm, dstGm, tilingData.softmaxTilingData);
    op.Process();
}
